The PCS55-C series are clamp-on current transformers. The CT can be mounted to existing panels, such as control centers or load centers, to measure or monitor wattage. These CTs can be mounted without removing existing cables for easier installation.
Measuring range:0 - 1000 A Measurement Frequency:50 - 60 Hz Special indicators:customizable.The PCS50-C series are clamp-on current transformers. The CT can be mounted to existing panels, such as control centers or load centers, to measure or monitor wattage. These CTs can be mounted without removing existing cables for easier installation.
| MODEL | INPUT CURRENT | AVAILABLE OUTPUT |
| PCS50100-C | 100 A | CURRENT OUTPUTS @ 20 mA, 40 mA, 100 mA, 1 A, 5 A VOLTAGE OUTPUTS @ 0.333 V, 1 V, 2 V |
| PCS50200-C | 200 A | |
| PCS50300-C | 300 A | |
| PCS50500-C | 500 A | |
| PCS501000-C | 1000 A |
| Energy and sub-metering products |
| Electrical load monitoring |
| Network equipment |
| Instruments and sensors |
| Control systems |
| Go GREEN initiatives |
| 1” window opening (lD) |
| M4 terminal output |
| Approximate weight 400 g |
| Standard Input Current 1 - 1000 A |
| Frequency 50 Hz - 60 Hz |
| Standard accuracy 0.5, 1 |
| Insulation Voltage 4000 Vac / 1 min |
| Operating Temp. - 40 °C to + 70 °C |
| Storage Temp. - 45 °C to + 85 °C |
