The PCSL24 Series are split-core current transformers. The CT can be mounted to existing panels, such as control centers or load centers, tomeasure or monitor wattage. These CTs can be mounted without removing existing cables for easier installation..
The PCSL24 Series are split-core current transformers. The CT can be mounted to existing panels, such as control centers or load centers, tomeasure or monitor wattage. These CTs can be mounted without removing existing cables for easier installation.
| MODEL | INPUT CURRENT | AVAILABLE OUTPUT |
| PCSL24-50 | 50A | CURRENT OUTPUTS @ 20mA, 33.3mA, 40mA, 50mA, 100mA, 1A, 5A VOLTAGE OUTPUTS @ 0.25V, 0.33V, 0.5V, 1V, 2V Output can be customized by customer |
| PCSL24-100 | 100A | |
| PCSL24-200 | 200A | |
| PCSL24-300 | 300A | |
| PCSL24-400 | 400A |
| Energy and sub-metering products |
| Electrical load monitoring |
| Network equipment |
| Instruments and sensors |
| Control systems |
| Go GREEN initiatives |
| Custom design Turns-Ratio available |
| Approximate weight 240g |
| Standard Input Current 0.1 - 400A |
| Frequency 50Hz - 400Hz |
| tandard accuracy 0.5, 1, 3 |
| Insulation Voltage 4000 Vac/1min |
| Operating Temp. - 40°C to + 70°C |
| Storage Temp. - 45°C to +85°C |
